LM3480IM3X-3.3/NOPB General Purpose Relays Lm3480im3x-3.3/Nopb

Name: LM3480IM3X33NOPB General Purpose Relays Lm3480im3x33Nopb
Brand: original
Price: 1 USD

Brand Name : original

Model Number : LM3480IM3X-3.3/NOPB

Certification : original

Place of Origin : original

MOQ : 1

Price : negotiation

Payment Terms : T/T, L/C

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Product Status : Active

Output Configuration : Positive

Output Type : Fixed

Number of Regulators : 1

Voltage - Input (Max) : 30V

Voltage - Output (Min/Fixed) : 3.3V

Current - Output : 100mA

Voltage Dropout (Max) : 1.2V @ 100mA

Contact Now

LM3480IM3X-3.3/NOPB General Purpose Relays Lm3480im3x-3.3/Nopb

Linear Voltage Regulator IC Positive Fixed 1 Output 100mA SOT-23-3

Specifications of LM3480IM3X-3.3/NOPB

TYPE	DESCRIPTION
Category	Integrated Circuits (ICs)
	Power Management (PMIC)
	Voltage Regulators - Linear
Mfr	Texas Instruments
Series	-
Package	Tape & Reel (TR)
	Cut Tape (CT)
	Digi-Reel®
Product Status	Active
Output Configuration	Positive
Output Type	Fixed
Number of Regulators	1
Voltage - Input (Max)	30V
Voltage - Output (Min/Fixed)	3.3V
Voltage - Output (Max)	-
Voltage Dropout (Max)	1.2V @ 100mA
Current - Output	100mA
Current - Quiescent (Iq)	2 mA
PSRR	-
Control Features	-
Protection Features	Over Current, Over Temperature
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23-3
Base Product Number	LM3480

Features of LM3480IM3X-3.3/NOPB

• Input Voltage Range: up to 30 V

• 3.3-V, 5-V, 12-V, and 15-V Versions Available

• Packaged in the Tiny 3-Lead SOT-23 Package

• 30-V Maximum Input for Operation

• 1.2-V Ensured Maximum Dropout Over Full Load and Temperature Ranges

• 100-mA Ensured Minimum Load Current

• ±5% Ensured Output Voltage Tolerance Over Full Load and Temperature Ranges

• −40 to +125°C Junction Temperature Range for Operation

Applications of LM3480IM3X-3.3/NOPB

• Tiny Alternative to LM78Lxx Series and SimilarDevices
• Tiny 5-V ±5% to 3.3-V, 100-mA Converter
• Post Regulator for Switching DC/DC Converter
• Bias Supply for Analog Circuits

Environmental & Export Classifications of LM3480IM3X-3.3/NOPB

ATTRIBUTE	DESCRIPTION
RoHS Status	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
